Adopt precise SMT component, lock wire design, more reliable and durable!

1. It conforms to DMX-512/1990 international standard protocol and has 512 circuits.

2. Plug and play, no install and drive, green and reliable, very good compatibility;Support WinXP/ Win7/8/10 or higher.

3, arbitrary plug and plug, no error or crash, automatic tracking and synchronous computer control.

4. Adopt the latest high-speed 32-bit ARM processor and hardware USB2.0 full speed communication real-time control 512 channel.

5. Internal short-circuit protection circuit;DMX output adopts TVS transient protection and absorbs the impact of high pressure surge to ensure long-term reliable operation of the product.

6. Equipped with USB connection guard dog, in case of USB disconnect due to interference, the computer can be quickly and automatically restored to synchronize, so as to ensure a long time of automatic and reliable work.

7. Support ArtNet wired wireless network lighting protocol, which can be used as ArtNet Node with remote control.

8, can provide secondary development of VB,VC, C# and other interfaces, you can write their own control software.

9. Support more than 10 sets of stage lighting control software and 3D simulation:

Description of hardware interface definition

Canon head pin definition (consistent with DMX512 standard definition) :

1 Foot -- GND

2 feet -- Data-

3 feet -- Data+
